户用一体式储能系统
X1-IES (性活题材小说)
- 2.5K / 3.7K / 4.6K / 5K / 6K / 8K (性活题材小说)
- 观看视频
"免费阅读完整版" Product Advantage
The X1-IES supports up to 200% PV input and EPS output for 10 seconds, enabling superior energy utilization during peak loads 少妇小说在线. AI readiness and VPP integration capabilities future-proof your energy system while ensuring seamless scalability.
Assured Reliability (少妇性活BBBBBBBBB小说)
IP66 protection degree
Type II SPD on AC&DC side
AFCI protection (optional)
UPS-level switchover time<10ms
Smart Management
Al ready, forecasting solar generation and home consumption for
smart energy management strategy control*
VPP ready with a variety of compatibility(OpenADR, IEEE2030. 5, FCAS, API)** 少妇性活BBBBBBBBB小说.
Smart loads management (e. g. , heat pump, smart EV charger) 少妇小说免费.
Micro-grid support for real-time grid/off-grid balancing
Wireless meter compatibility
Global MPP scan for optimal energy harvest
"免费阅读完整版" Flexible Adaptability
All-in-one, plug-and-play design
Max BBBBBBBBB情节. 20A DC input current for high power solar panel.
"少妇小说在线" High Performance
Max. 50A charge/discharge current
200% oversizing and 200% PV input power
Up to 200% EPS output for 10s
Low start-up voltage for longer operation
Cycle life > 6000 times
Rated output power | 2500 W |
Rated AC voltage | 1/N/PE,220/230/240V |
Rated EPS output power | 2500 VA |
Peak EPS output power | 2 times of rated power, 10 s |
| Switchover time | <10 ms |
Battery type | Li-ion (LFP) |
Max Charge / Discharge current | 50 A |
| Ingress protection | IP66 |
Dimensions (W x H x D) | 717x350x210 mm |
| Net Weight | 26.2 kg |
- PV INPUT
Max. recommended PV array power
6.0 kWp
MPPT voltage range
40~560 V
Number of MPP. trackers / strings per MPPT
2/(1/1)
Max. input current per MPPT
20 A/20 A
- AC INPUT & OUTPUT(ON-GRID)
Rated output power
3000 W
Rated AC voltage
1/N/PE,220/230/240V
- EPS(OFF-GRID) OUTPUT(WITH BATTERY)
Rated EPS output power
3000 VA
Peak EPS output power
2 times of rated power, 10 s
Switchover time <10 ms
- BATTERY MODEL
Battery type
Li-ion (LFP)
Max Charge / Discharge current
50 A
Ingress protection IP66
- GENERAL
Dimensions (W x H x D)
717x350x210 mm
Net Weight 26.2 kg
- PV INPUT
Max. recommended PV array power
7.4 kWp
MPPT voltage range
40~560 V
Number of MPP. trackers / strings per MPPT
2/(1/1)
Max. input current per MPPT
20 A/20 A
- AC INPUT & OUTPUT(ON-GRID)
Rated output power
3680 W
Rated AC voltage
1/N/PE,220/230/240V
- EPS(OFF-GRID) OUTPUT(WITH BATTERY)
Rated EPS output power
3680 VA
Peak EPS output power
2 times of rated power, 10 s
Switchover time <10 ms
- BATTERY MODEL
Battery type
Li-ion (LFP)
Max Charge / Discharge current
50 A
Ingress protection IP66
- GENERAL
Dimensions (W x H x D)
717x350x210 mm
Net Weight 26.2 kg
- PV INPUT
Max. recommended PV array power
10.0 kWp
MPPT voltage range
40~560 V
Number of MPP. trackers / strings per MPPT
3/(1/1/1)
Max. input current per MPPT
20A/20A/20 A
- AC INPUT & OUTPUT(ON-GRID)
Rated output power
5000 W
(4600 for VDE41054999 for AS4777)
Rated AC voltage
1/N/PE,220/230/240V
- EPS(OFF-GRID) OUTPUT(WITH BATTERY)
Rated EPS output power
5000 VA
Peak EPS output power
2 times of rated power, 10 s
Switchover time <10 ms
- BATTERY MODEL
Battery type
Li-ion (LFP)
Max Charge / Discharge current
50 A
Ingress protection IP66
- GENERAL
Dimensions (W x H x D)
717x350x210 mm
Net Weight 26.4 kg
- PV INPUT
Max. recommended PV array power
12.0 kWp
MPPT voltage range
40~560 V
Number of MPP. trackers / strings per MPPT
3/(1/1/1)
Max. input current per MPPT
20 A/20 A/20 A
- AC INPUT & OUTPUT(ON-GRID)
Rated output power
6000 W
Rated AC voltage
1/N/PE,220/230/240V
- EPS(OFF-GRID) OUTPUT(WITH BATTERY)
Rated EPS output power
6000 VA
Peak EPS output power
2 times of rated power, 10 s
Switchover time <10 ms
- BATTERY MODEL
Battery type
Li-ion (LFP)
Max Charge / Discharge current
50 A
Ingress protection IP66
- GENERAL
Dimensions (W x H x D)
717x350x210 mm
Net Weight 26.4 kg
- PV INPUT
Max. recommended PV array power
16.0 kWp
MPPT voltage range
40~560 V
Number of MPP. trackers / strings per MPPT
3/(1/1/1)
Max. input current per MPPT
20 A/20 A/20 A
- AC INPUT & OUTPUT(ON-GRID)
Rated output power
8000 W
Rated AC voltage
1/N/PE,220/230/240V
- EPS(OFF-GRID) OUTPUT(WITH BATTERY)
Rated EPS output power
8000 VA
Peak EPS output power
2 times of rated power, 10 s
Switchover time <10 ms
- BATTERY MODEL
Battery type
Li-ion (LFP)
Max Charge / Discharge current
50 A
Ingress protection IP66
- GENERAL
Dimensions (W x H x D)
717x350x210 mm
Net Weight 26.4 kg
